"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" FLEXIBLE TUBE FOR PILOT OIL (FTSP – 10)                         DWG : 32-12915B MITSUBISHI.MCC-180.M-4

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" ATOMIZER FOR PILOT BURNER (AP-2.5-60) 42-10898 MITSUBISHI.MCC-180.8

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" HE PLUG (32-4855) (HE IGNITER PLUG CARRIER) MITSUBISHI.MCC-180.32-4855

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" SPACER FOR HE IGNITOR MITSUBISHI.MCC-180.HE-S

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" PLUG FOR HE IGNITOR MITSUBISHI.MCC-180.HE-P

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" "RELAY  RXG21BD

24 VDC

5A/ 250 VAC

IEC61810-1

UL RATINGS

5A/250 VAC

5A/30 VDC

 1/6 HP/240 VAC

TELEMECANIQUE

8A-2022-W16-A-X

MAKER:SCHNEIDER

ELECTRIC             RXG 24 VDC" MITSUBISHI.MCC-180.Boiler water level  panel

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" "AUXILIARY RELAY   SR-K8                  SR –K4      2A 2B( 2NO 2NC)

JIS C4531

IEC337-1

AC11 DC11

110V  6A 0.8A

220V 5A 0.2A

Ith=16A

VDE 0660 BS 4794

MITSUBISHI  ELECTRIC CORPORATION  JAPAN" MITSUBISHI.MCC-180.Boiler main control panel

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" "AUXILARY RELAY

UA-AX4

94.YB

JIS  C4531 IEC 337-1

AC 11  DC 11

110 V  6A   0.8 A

220 V 5A    0.5 A            A600

Ith 16A

                     MITSUBISHI   ELECTRIC CORPORATION JAPAN.

BH518Z908HO1" MITSUBISHI.MCC-180.Boiler main control panel.

"FOR BOILER

MAKER:MITSUBISHI

MODEL NO.MCC-180" "TIMER H3BA

OMRON H3BA-N

SOURCE  110V AC 50/60/HZ

CONTACT 5A 250 VAC  RESISTIVE LOAD

LOI NO. 1425S

OMRON CORPORATION MADE IB CHIANA" MITSUBISHI.MCC-180.NA
